Infrasound Signals from the Re-entry and Explosion of the Space Shuttle Columbia, 01 February 2003. The infrasonic acoustic sensors at the NVAR array in Nevada and the TXAR array in south Texas recorded the N-waves (sonic booms) and subsequent disintegration of the space shuttle as it passed over Neveda, New Mexico, and North Texas. The timing and location of these events are calculated from the azimuths and arrival times of the signals.



Synchronization of Video with Seismic and Acoustic Data using GPS
A technique for recording GPS timing signals on video tape for correlation with seismic and acoustic data sets. This paper is also available as an MS Word Document (1.5 Meg).


Bulk Mining Shot mpeg (1.7M) 200 Hz Broadband and Hi-pass Acoustic Signal. Waveforms are time aligned with GPS synchronized video for broadband and high-pass filtered signals. Time stamps display UTC and elapsed time for the blast. The video has been de-interlaced to produce a slow motion (1/2 speed) display with a resolution of 16.667 milliseconds per frame.

Passing Cars mpeg (2.4M) Broadband and Hi-Pass Signals with time aligned GPS-synchronized video, illustrating pressure wave as vehicles pass the two acoustic sensors located about 20 feet apart on the grass between curb and sidewalk.

Train Entering Tunnel mpeg (6.6m) Broadband Acoustic and Seismic Signals with time aligned GPS-synchronized video. Acoustic pressure gauges are placed along the side and above the tunnel entrance, and seismometers are placed on the wall directly above the tunnel. The broadband acoustic waveform is displayed at the top of the image with the three-axis seismic signals beneath.

Infrasound Site Survey

Noise Survey for Wake Island: methodology, data acquisition equipment, data processing technique, micropressure data, meteorological data, instantaneous wind speed, recommendations, and PTS response.
